Arrow Steel and Alloys is a reputable name in the realm of piping solutions, renowned for its commitment to quality and precision engineering. Among its extensive range of products, butt-welded pipe fittings stand out as a cornerstone of reliability and durability. These fittings, manufactured by Arrow Steel and Alloys, exemplify the highest standards in the industry. Butt-welded pipe fittings are vital components in piping systems, seamlessly connecting pipes and enabling the smooth flow of fluids. Arrow Steel and Alloys ensures that their butt-welded fittings meet stringent specifications, adhering to international standards and certifications. With a focus on excellence, the company employs advanced manufacturing techniques, cutting-edge technology, and a meticulous quality control process to produce fittings that guarantee optimal performance and longevity.
Stainless steel butt-welded fittings find widespread application in architectural structures for robust structural connections. These fittings are commonly available in larger dimensions, boasting diameters that provide sturdy support and lengths extending up to 6 meters. On the other hand, butt-welded fittings crafted for precision applications in machinery or pipeline systems are often smaller in diameter, ranging from a few centimeters to inches. This design flexibility ensures an optimal fit and adaptability to meet specific industrial and mechanical requirements.
| BW Fittings ANSI B16.9 Tolerance (45 And 90 degree) Elbow, End Cap, Tee, Reducer) |
90 Deg. & 45 Deg. Elbow and Tee |
Reducer & Long Lap Joint Stub End |
Cap | |||
|---|---|---|---|---|---|---|
| Fitting Dimension (NPS) |
Outside Daimeter Diameter at Bevel |
Inside Diameter at End |
Wall Thick T |
Center-to-End Dimension A ,C ,B |
Over-all Length H |
Over-all Length F |
| 1/2 to 2-1/2 | +0.06 | Not less than 87.5% of nominal Thickness |
+/- 0.06 | +/- 0.06 | +/- 0.12 | |
| -0.03 | ||||||
| 3 to 3-1/2 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.12 | |
| 4 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.12 | |
| 5 to 8 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.06 | +/- 0.25 | |
| 10 to 18 | +0.16 | +/- 0.12 | +/- 0.09 | +/- 0.09 | +/- 0.25 | |
| -0.12 | ||||||
| 20 to 24 | +0.25 | +/- 0.19 | +/- 0.09 | +/- 0.09 | +/- 0.25 | |
| -0.19 | ||||||
| 26 to 30 | +0.25 | +/- 0.19 | +/- 0.12 | +/- 0.19 | +/- 0.38 | |
| -0.19 | ||||||
| 32 to 48 | +0.25 | +/- 0.19 | +/- 0.19 | +/- 0.19 | +/- 0.38 | |
| -0.19 | ||||||
Butt-welded fittings come in a wide array of sizes, covering diverse dimensions tailored to meet specific requirements in industrial settings. The customization possibilities for these fittings extend to factors like size, type, and facing, offering adaptability to the unique needs of each project. Despite potential variations in standard dimensions, the inherent flexibility of butt-welded fittings allows for bespoke solutions, addressing specific needs such as varying sizes, facing preferences, or the inclusion of particular features. This versatility extends across different materials, guaranteeing the delivery of customized fitting solutions to fulfill the varied demands of various industries and applications.
| Description | Price In INR (Per Piece) |
|---|---|
| Buttweld A234 GR.WPB 90º SMLS Elbow | |
| 2" X SCH 40 | 225.00 |
| 3" X SCH 40 | 300.00 |
| 4" X SCH 40 | 500.00 |
| 6" X SCH 40 | 1150.00 |
| ASME B16.9 SMLS Equal Tee ASTM A234 GR.WPB | |
| 3/4 X 40 | 140.00 |
| 1/2 X 40 | 120.00 |
| 2" X 40 | 320.00 |
| Buttweld 45º SMLS Elbow ASTM A234 GR.WPB | |
| 6" X SCH 40 | 750.00 |
| 8" X SCH 40 | 1400.00 |
| 10" X SCH 40 | 2800.00 |
| Buttweld Con. Reducer ASTM A234 GR.WPB | |
| 3/4 X 1/2 X SCH 160 | 80.00 |
| 1 X 1/2 X SCH 160 | 110.00 |
| 4 X 2 X SCH 80 X SCH 160 | 550.00 |
